Basic Info.
Part no. | 1105096 | Material | steel |
Type | Cylinder Head | Part Type | |
Compatibility | Caterpillar 3406B | Transport Package | Wooden box |
Trademark | DIRON | Origin | Luoyang City |
HS Code | 84099991 | Production Capacity | 5000PCS/Year |
Product Details
Item Model： 1105096
Date First Listed：2025/06/20
Manufacturer：Diron Parts
Product Description
Part Number：1105097
Part Type：Cylinder Head
Description: Replacement Part Cylinder Head 1105096 for Caterpillar 3406B, New
Cylinder Head 1105096 for Caterpillar 3406B
Product Introduction: Cylinder Head 1105097 for Caterpillar 3406A Diesel Engine
Overview
The Cylinder Head 1105097 is a precision-engineered component designed for the Caterpillar 3406A diesel engine, critical for sealing the combustion chamber, housing the valves, and facilitating efficient airflow and fuel combustion. This part is essential for maintaining engine performance and reliability in heavy-duty applications, such as wheel tractors, trucks, and industrial equipment. Available as a new aftermarket, remanufactured, or genuine OEM part, it provides a robust solution for engine maintenance.
Key Features
Dimensions: Specific dimensions are not fully detailed in public sources, but approximate measurements for 3406 heads are 1028.7 mm (length), 393.7 mm (width), and 292.1 mm (height), based on similar 3406 heads (e.g., 1105096). Typical bare cylinder heads weigh approximately 200-250 lbs (91-113 kg), with loaded assemblies heavier due to pre-installed components.
Material: Constructed from high-grade cast iron, designed to withstand high temperatures, pressures, and mechanical stresses in the 3406A engine. Features precision-machined surfaces for optimal sealing, heat dissipation, and durability.
Design: Engineered to OEM specifications for precise fitment and performance. Includes valve seats, guides, and ports optimized for efficient combustion and exhaust flow. Available as a bare head (with valve guides and seats) or loaded assembly with pre-installed valves, springs, premium valve stem seals, retainers, and injector cups. Features advanced cooling passages to manage engine temperature effectively.
Compatibility: Compatible with Caterpillar 3406A diesel engines, used in:
Wheel Tractors: 627B, 627E, 627F.
Trucks: 3406, D400, for heavy-duty hauling.
Industrial Engines: 3406, used in generator sets, pumps, and compressors.
Other Applications: Articulated dump trucks (D35HP, D400), wheel loaders (980C), and track-type tractors (D8N).
Engines: 3406A (inline 6-cylinder, 14.6L, 2-valve per cylinder configuration), with specific serial numbers (e.g., 90U, 11N, 70V). Exact compatibility must be verified using the engine’s serial number via CAT SIS, as per Caterpillar’s policy.
Cross-References: 1105097, 110-5097, CA1105097, 1105095, 1105096, 1105099, 7N1303, 7W0006, 7W0007, 7W0009, 7W0010, 7W2200, 7W2202, 7W2203, 0R0977, 0R1445, 0R3673, 0R3676, 0R3719, and others. The 1105097 is interchangeable with heads for 3406A, 3406B, and some 3406C models, often sharing casting numbers like 7W0009.
